Clarion TTX 7503Z [6/9] English

TTX7503z 7

English

5. TROUBLESHOOTING

The following symptoms may not be the result of a breakdown, so perform the remedy suggested

below before contacting your Dealer for repairs.

Check the wiring method in the manual again,

then connect the wiring properly.

Check that the parking brake is engaged

completely.

Check the connection method in the manual

again, then connect the wiring properly.

The transmission may not be reaching you

properly because you are in a valley or the

shadow of a building. Check again at a location

where the transmission can reach you properly.

The image may be affected by transmission

reflected from

mountains or buildings. Change your location or

the reception

direction.

Reception may be affected by radio interference

from another

vehicle, a train, high voltage or neon signs.

Check your

reception again at another location.

No power

No image

Unclear image from

rear seat monitor

Image is unclear

Double or triple image

Image is spotty or

striped

Wiring is incomplete.

Parking brake is not engaged.

Image output for front and

rear is connected in reverse.

Poor reception

Electrical interference

Symptom Cause Remedy
