Functions of Buttons
9
VX709E
English
Owner’s manual
[R], [F] buttons
• Use these buttons to change to the previous/
next preset station in the TUNER mode.
• In the DVD Video mode, use these buttons to
select a chapter to be played.
Keep pressing a button during playback
performs the fast backward or fast forward
playback.
Keep pressing the [F] button during pausing
performs the slow playback.
• In the CDDA, MP3/WMA/AAC/DivX, and iPod/
USB Memory/Bluetooth (Audio) modes, use
these buttons to select a track to be played.
Keep pressing a button during playback
performs the fast backward or fast forward
playback.
[MENU] button
• Press this button to display the Menu screen.
You can change the system settings from this
screen.
• When displaying the General Settings screen,
keep pressing this button more than 2 seconds
to display a screen for entering your personal
code of the anti-theft function.
[MAP] button
*1
• Pressing this button in the audio/visual modes
changes to the Navigation mode.
[ ] (Voice/SEND/END) button
*2
• When a call comes in, press this button to
answer the call.
• During a call, press this button to end the call.
• When a navigation system is connected, press
this button to display the Voice Command
screen of the navigation system.
[TA] button
• Press this button to turn on/off the TA (Traffic
Announcement) standby mode.
• Keep pressing this button more than 1 second
to turn on/off the Auto Antenna function (see
page 63).
[7] (OPEN/CLOSE) button
• Use this button to open/close the operation
panel.
• Keep pressing this button to adjust the angle of
the operation panel. The angle of the operation
panel is adjustable in the range of 0q to 30q.
Blink LED
• When the Blink LED function is set to “ON” from
the System tab menu on the General Settings
screen, blinks when the ACC power is turned
off.
Note:
*1 This button is available only when a navigation
system is connected.
*2 This button is available only when a navigation
system is connected or the connection with a
Bluetooth telephone is established. However, the
Voice Command operation is not possible with
the navigation system NP509E.
