8
Gb
English
system and wear a suitable dust protection mask. Remove deposited dust
thoroughly, e.g. with a vacuum cleaner.
Do not use machines on any material containing asbestos.
This machine is suitable only for dry sanding.
The oscillating sander can be used for sanding wood, plastics and metal.
Do not use this product in any other way as stated for normal use.
We declare under our sole responsibility that this product is in conformity
with the following standards or standardized documents: EN 60745,
EN 55014-1, EN 55014-2, EN 61000-3-2, EN 61000-3-3, in accordance
with the regulations 2006/42/EC, 2004/108/EC
Connect only to single-phase AC current and only to the system
voltage indicated on the rating plate. It is also possible to connect to
sockets without an earthing contact as the design conforms to safety
class II.
The ventilation slots of the machine must be kept clear at all times.
Use only AEG accessories and spare parts. Should components need to be
replaced which have not been described, please contact one of our service
agents (see our list of guarantee/service addresses).
If needed, an exploded view of the tool can be ordered. Please state the
Article No. as well as the machine type printed on the label and order the
drawing at your local service agents or directly at: AEG Elektrowerkzeuge,
Max-Eyth-Straße 10, D-71364 Winnenden, Germany.
Please read the instructions carefully before starting the
machine.
CAUTION! WARNING! DANGER!
Always disconnect the plug from the socket before carrying out
any work on the machine.
Accessory - Not included in standard equipment, available as
an accessory.
Do not dispose of electric tools together with household
waste material! In observance of European Directive 2002/96/
EC on waste electrical and electronic equipment and its
implementation in accordance with national law, electric
tools that have reached the end of their life must be collected
separately and returned to an environmentally compatible
recycling facility.
FDS 140
Rated input .....................................................260 W
No-load speed .............................................14000 min
-1
Orbital travel diameter ......................................1,6 mm
Dimensions of grinding plate .................
110 x 105 mm ..110 / 110 mm
Weight without cable........................................
1,5 kg .............. 1,6 kg
Noise/vibration information
Measured values determined according to EN 60 745.
Typically, the A-weighted noise levels of the tool are:
Sound pressure level (K = 3 dB(A)) .................76,5 dB(A).......82,0 dB(A)
Sound power level (K = 3 dB(A)).....................87,5 dB(A).......93,0 dB(A)
Wear ear protectors!
Total vibration values (vector sum in the three axes)
determined according to EN 60745.
Vibration emission value a
h
...............................4,8 m/s
2
........10,0 m/s
2
Uncertainty K= .................................................1,5 m/s
2
..........1,5 m/s
2
WARNING!
The vibration emission level given in this information sheet has been
measured in accordance with a standardised test given in EN 60745 and
may be used to compare one tool with another. It may be used for a
preliminary assessment of exposure.
The declared vibration emission level represents the main applications
of the tool. However if the tool is used for dierent applications, with
dierent accessories or poorly maintained, the vibration emission may
dier. This may signicantly increase the exposure level over the total
working period.
An estimation of the level of exposure to vibration should also take into
account the times when the tool is switched o or when it is running but
not actually doing the job. This may signicantly reduce the exposure level
over the total working period.
Identify additional safety measures to protect the operator from the
eects of vibration such as: maintain the tool and the accessories, keep
the hands warm, organisation of work patterns.
WARNING!
Read all safety warnings and all instructions, including those given in
the accompanying brochure. Failure to follow the warnings and instructions
may result in electric shock, re and/or serious injury. Save all warnings and
instructions for future reference.
Wear ear protectors.
Exposure to noise can cause hearing loss.
Appliances used at many dierent locations including open air should be
connected via a residual current device of 30 mA or less.
Always wear goggles when using the machine. It is recommended to wear
gloves, sturdy non slipping shoes and apron.
Always disconnect the plug from the socket before carrying out any work
on the machine.
Only plug-in when machine is switched o.
Keep mains lead clear from working range of the machine. Always lead the
cable away behind you.
Before use check machine, cable, and plug for any damages or material
fatigue. Repairs should only be carried out by authorised Service Agents.
The dust produced when using this tool may be harmful to health (e.g.
when working oak or beech wood, stones, paint, which could contain lead
or other harmful chemicals). Do not inhale the dust. Use a dust absorption
Rainer Kumpf
Manager Product Development
Authorized to compile the technical file
Winnenden, 2010-11-17
