ASSEMBLY

CAUTION:

• Always be sure that the tool is switched off and the

battery cartridge is removed before carrying out

any work on the tool.

Installing or removing drill bit

For model DA330D

Fig.6

To install the bit, place it in the chuck as far as it will go.

Tighten the chuck by hand. Place the chuck key in each

of the three holes and tighten clockwise. Be sure to

tighten all three chuck holes evenly.

To remove the bit, turn the chuck key counterclockwise

in just one hole, then loosen the chuck by hand.

After use, return the chuck key to the storage cavity on

the tool.

For model DA331D

Fig.7

Hold the tool firmly and turn the sleeve

counterclockwise to open the chuck jaws. Place the bit

in the chuck as far as it will go. Hold the tool firmly turn

the sleeve clockwise to tighten the chuck.

To remove the bit, hold the tool firmly turn the sleeve

counterclockwise.

Chuck key holder

For model DA330D

Fig.8

To install the chuck key holder, point the hook portion of

it toward the housing. Then insert the rails of the chuck

key holder to the slots of the tool housing until it locks in

place with a little click.

To remove, hold the chuck key holder and then take it

out.

OPERATION

CAUTION:

• Hold the tool firmly with one hand on the gripping

part of the tool when performing the tool.

For model DA330D

Fig.9

For model DA331D

Fig.10

Drilling operation

Drilling in metal

To prevent the bit from slipping when starting a hole,

make an indentation with a center-punch and hammer

at the point to be drilled. Place the point of the bit in the

indentation and start drilling.

Use a cutting lubricant when drilling metals. The

exceptions are iron and brass which should be drilled

dry.

CAUTION:

• Pressing excessively on the tool will not speed up

the drilling. In fact, this excessive pressure will

only serve to damage the tip of your bit, decrease

the tool performance and shorten the service life

of the tool.

• There is a tremendous force exerted on the tool/bit

at the time of hole break through. Hold the tool

firmly and exert care when the bit begins to break

through the workpiece.

• A stuck bit can be removed simply by setting the

reversing switch to reverse rotation in order to

back out. However, the tool may back out abruptly

if you do not hold it firmly.

• Always secure small workpieces in a vise or

similar hold-down device.

• If the tool is operated continuously until the battery

cartridge has discharged, allow the tool to rest for

15 minutes before proceeding with a fresh battery.

MAINTENANCE

CAUTION:

• Always be sure that the tool is switched off and the

battery cartridge is removed before attempting to

perform inspection or maintenance.

• Never use gasoline, benzine, thinner, alcohol or

the like. Discoloration, deformation or cracks may

result.

To maintain product SAFETY and RELIABILITY, repairs,

any other maintenance or adjustment should be

performed by Makita Authorized Service Centers,

always using Makita replacement parts.

OPTIONAL ACCESSORIES

CAUTION:

• These accessories or attachments are

recommended for use with your Makita tool

specified in this manual. The use of any other

accessories or attachments might present a risk of

injury to persons. Only use accessory or

attachment for its stated purpose.

If you need any assistance for more details regarding

these accessories, ask your local Makita Service Center.

• Drill bits

• Chuck key

• Chuck key holder

• Plastic carrying case

• Makita genuine battery and charger

NOTE:

• Some items in the list may be included in the tool

package as standard accessories. They may differ

from country to country.
