- Ensure good ventilation of the workplace and
keep clean using a vacuum cleaner. Sweeping or
blowing stirs up dust.
- Vacuum or wash the protective clothing. Do not
blow, beat or brush.
See page 2.
1 Additional handle *
2 Wing screw (for adjusting the depth stop) *
3Depth stop *
4Clamping knob *
5 Bar handle (additional handle) *
6 Dust protection cap
7Tool lock
8Knob
9 Metabo VibraTech (MVT): integrated damping
system
10 Locking lever (to release the continuous
operation) *
11 Trigger
12 Handle
13 Adjustment wheel
14 Overloading and service display
15 Mode display
* equipment-specific
Before plugging in, check that the rated mains
voltage and mains frequency, as stated on the
type plate match your power supply.
Always install an RCD with a maximum trip
current of 30 mA upstream.
Use only extension cables with a minimum cross-
section of 1.5 mm
2
. Extension cables must
correspond to the power consumption of the
machine (cf Technical Specifications). If a cable
roller is used, always roll up the cable completely.
6.1 Assembly of the bow handle or
additional handle
For safety reasons, always use the bow
handle (5) or additional handle (1) supplied.
MHE 5:
Release the clamping ring by turning the clamping
knob (4) anticlockwise. Adjust the bow handle (5) to
the required position and angle. Tighten the
clamping knob firmly.
KHE 5-40:
Open the clamping ring by turning the additional
handle (1) anticlockwise. Secure the additional
handle at the required angle. Tighten the additional
handle.
7.1 Depth Stop Setting
(only for KHE 5-40)
Release the wing (2) screw. Set the depth stop (3)
to the required drilling depth. Retighten the wing
screw (2).
7.2 Positioning, removing tool
Before inserting, clean tool shank and apply
supplied special grease (accessories: Order
no. 6.31800)! Use only SDS-max tools.
The dust protection cap (6) prevents the
ingress of drilling dust during operation. When
inserting the tool, pay attention to ensure that the
dust protection cap (6) is not damaged.
Positioning tool:
Hold the tool lock (7) in the front position when
inserting the tool. Turn tool and insert until it
engages. The tool is being locked.
Pull on the tool to check that it is correctly
seated. (It must be possible to move the tool a
few centimetres in an axial direction.)
Remove the tool:
Pull the tool lock (7) backwards in direction
indicated by arrow (a) and remove tool (b). See
page 3.
7.3 Setting operating mode and chisel
position
Avoid levering with the machine when a chisel
is fitted.
KHE 5-40:
Do not activate the switch button (8) until the
motor has completely stopped.
Only rotate the switch button (8) in the
direction of the arrow.
Turn the switch button (8) to select the desired
operating mode.
Hammer drilling
Chiselling
Setting the position of the chisel:
The chisel can be
locked in different positions.
- Insert the chisel.
- Turn the switch button (8) to the intermediate
position (between setting and setting ).
- Turn the chisel to the required position.
- Turn the switch button (8) to position .
- Turn the chisel until it engages.
When a chisel is fitted, only operate the
machine in the chiselling operating mode .
MHE 5:
Only operate the switch button (8) when the
motor is at a standstill.
Chiselling
