48 496-006_v01
Part names (Fig. A)
1
Juice extractor motor
a
I-0-II switch
b
TURBO button
c
skimmer
d
vacuum cup
e
supply cord
2
Bowl
f
juice spout
g
outer n
h
inner n
3
Bowl insert
i
notch
4
Filter
5
Lid
6
Locking bar
7
Bowl for small fruits
8
Pusher
9
Juice collector
10
Foam separator
11
Lid of collector
12
Pulp collector
13
Brush
Preparations for operation
(disassembling) (Fig. B)
Disassemble the juice extractor before rst
usage and clean the parts in contact with
processed product.
1
Place the juice extractor near the socket on the rm,
clean and dry surface.
2
Pull down the locking bar (6) so that the tracks moved
out of grooves of the lid (5) from position 1 to position 2.
3
Take the pusher (8) out and remove the bowl (7) and
lid (5).
4
Then remove the bowl (2) including the insert (3) and
lter (4).
5
Then, disassemble the insert (3) from the bowl (2).
Wash the disassembled parts (apart from the
motor) carefully in hot water and wash-up
liquid. You can clean them in dishwasher in
max temp. 60ºC (apart from the motor and
lter). After drying carefully start assembling
the clean parts.
Preparations for operation
(assembling) (Fig. C)
1
Align the bowl (2) to the motor (1), so that the juice spout
(f) was placed exactly in the casing (1) groove and 4 buckles
from the upper part of the motor (1) were placed inside the
4 grooves in the bottom of the bowl (2).
2
Insert the bowl insert (3) to the bowl (2) so that the notch
(i) in the bowl insert (3) is located in the inner n (h) of the
bowl (2).
3
Put the lter (4) inside and check if it is well mounted and
rotates easily.
4
Install the lid (5) so that the outer n (g) of the bowl (2) is
in the notch of the lid (5).
5
Pay attention to assemble the parts correctly. The outer
n (g) of the bowl (2) should be in one line with the notch in
the lid (5).
6
Pull the locking bar (6) up, so that the rolls moved into
grooves of the lid (5) from position 2 to position 1 (you will
hear a characteristic clicking sound).
7
Each time insert a bowl for small fruit (7) on the feeder
opening of the cover (5).
8
Put the pusher (8) into the chute so that the V-shaped
hole was put on the knife inside the chute.
9
Put the pulp collector (12) under the lid (5) in the following
way: lean the collector and place it under the insert (3) and
lid (5), then push it towards the motor (1).
10
Put the juice collector (9) so that the juice spout (f) was
inside the collector (9).
Start-up and operation (Fig. D)
Check if the switch is turned to
●
„0” position.
1
Plug the juice extractor in and start it up with the switch
(a) setting as necessary gear 1 (position I – low rotation) or
gear 2 (position II – high rotation).
Such exemplar table including exact
information on selection of appropriate gear for
particular fruit and vegetables is on page 76.
2
Put some fruit or vegetables into chute and press them
slightly with the pusher.
You mustn’t push the products with your
ngers or other objects.
In case of the necessity (In case of excessive accumulation of
the pulp on the lter, which causes juice extractor vibrations)
you can use TURBO button (b). The engine operates in such
case on maximal rotation for approximately 2 seconds. After
this time, the TURBO function switches off automatically,
and the engine returns to previous rotation.
Repeated usage of TURBO function can take
place after min. 10 seconds.
