Positioning keys X/Y
Use the positioning keys to manually move the lens holder into the indicated directions.
When you press two keys simultaneously, the lens holder moves diagonally.
When you press the "Shift" key and one of the positioning keys simultaneously, a
movement to the corresponding end position is performed.
If all panels are closed, the movement is done with the maximum velocity, if
opened, the speed is 1/4th of the maximum.
While the Z- axis is in movement (e.g. autofocus), no cursor moves in X and Y axis
are performed.
The Autofocus option might not work on transparent materials or materials which
are not flat.
Bear in mind that defects from head crashes (working head hits material or working
table) are NOT warranted.
20
HOME
Pressing this button will change the machines home position temporary (Home-move to this po-
sition)
21
Manometer for gas pressure
22
Pressure regulator
This is used to adjust the required gas pressure of the gas used. The pressure setting is dis-
played on the: manometer for gas pressure.
