AEG SDH 175 15,6 Twin [19/60] Preparations

Installation - for contractors

 

The following accessories should be used when installing the system outdoors:

  

ZF 2200 Central charge controller (universal) 187620

ZFV 30 Central charge controller (forward controller) 184903

GF 2200-2 Central charge controller 187621

GF 2200-3 Central charge controller 187622

GF 2200-4 Central charge controller 187623

WRFF 2100 Temperature sensor 184902

FH DN 20 Sensor well 220379

RTEU 911 Decentralised charge controller with 7-day programming time switch 184993

RTE 910 Decentralised charge controller 184909

FRTD 903 Electronic Comfort all-in-one room and underfloor heating controller 229702

Optional combinations:

° ZF 2200 with GF 2200-x

° ZFV 30 with RTEU 911/RTE 910

° FRTD 903

 

» Remove any sharp edges or pointed objects that might protrude from the substrate and that might damage the heating

conductor.

» Clear the concrete area of any coarse contaminants. Level out any unevenness.

 

» Prior to commencement of any screed work, agree with the screed contractor the number, layout and implementation of

the expansion joints.

Provide expansion joints in doorways as well as in areas where the screed plate has a severe offset.

Create dummy joints where fixed components are let into the screed, such as pipes, columns or supports.

These joints are designed to accommodate the screed shrinkage that is subject to the building materials. In larger screed areas

it cannot be avoided that the cold conductors are routed through expansion joints.

» For this, route the cold conductors in the vicinity of the joint through two pipes pushed concentrically into each other.

The inner pipe of this joint bridge has the play in the axial and radial direction and is therefore able to accommodate the

shrinkage and expansion processes of the screed surface.





Individual screed areas can be up to 40 m

in size.

» When floating the screed ensure that the heating matt is completely encased in screed, i.e. so that gaps are prevented.
