OPERATION PROCEDURE (See figs. 15 & 16)
TURNING ON THE AIR CONDITIONER
Press START/STOP button (1) to turn on the air
conditioner. Operation Indicator (B) on the air
conditioner will light up, indicating that the unit is in
operation. Note that the LCD operation display (11) will
always show the last mode of operation and the
previous function used.
1
VENTILATING OPERATION
Select the FAN mode by pressing MODE button (2).
Switch to the desired fan speed or AUTO speed by
pressing FAN speed button (3).
COOLING OPERATION
Select the COOLING mode by pressing MODE button
(2). Switch to the desired fan speed or to AUTO fan by
pressing button (3). Select suitable temperature
setting.
This operation starts at the highest airflow, in order to
quickly lower the room temperature. It will then
automatically switch to low air flow, in order to quietly
maintain the selected temperature.
COOLING OPERATION WITH AUTO FAN MODE
* NOTE: The heating modes are used on units with cooling and heating.
English 16
2
3
2
3
45
2
3
