DESCRIPTION
Electro-Mechanical models 3.1 KW (R407C)
Figure 1: Indoor and Outdoor Unit components Description (Front)
Electronic models 3.1 KW (R407C)
Electro-Mechanical models 4.1 KW (R22/R410A)
3.1 KW (R410A)
Figure 2: Indoor and Outdoor Unit components Description (Front)
Electronic models 4.1 KW (R22/R410A)
3.1 KW (R410A)
1. Control buttons (for electromechanical model)
2. Indicators (leds)
3. Adjusting air supply grille
4. Carrying handle
5. Water tank door
6. Castors
7. Interconnecting hose
8. Carrying handle -outdoor unit
9. Water basin
10. Condenser fan grille
11. Remote control (for electronic model only)
English 3
1
2
3
4
5
6
10
9
7
8
11
11
8
9
10
2
3
4
5
6
1
7
