Page 3
English
3 - Description
3.1 - Inspection and Storage
When the equipment is received, all items must be carefully
checked against the bill of lading to be sure all crates and
cartons have been received. The units are shipped in carton.
Inspect all units for visible or concealed damages.
In case of deterioration, formulate the precise reserves
on the transport document and send immediately a
3.2 - Electrical Data
Standard motor data
3.3 - Operating Limits
registered letter to the forwarder, mentioning clearly the
occured damages and a copy of the letter to the
manufacturer or its representative.
Do not stand or transport the unit on its end. Temporary
storage must be indoor, completely sheltered from rain,
snow, etc. Change in the weather (high and low
temperatures) should not damage the unit. Excessively high
temperature (60 °C or more) may deteriorate certain plastic
materials and cause permanent damages. In addition,
some electric components may not operate correctly.
Maximum operating pressure 10 bar
Water piping system
Minimum entering temperature + 45 °C
Maximum entering temperature + 120 °C
Room air temperature
Minimum temperature - 15 °C
Maximum temperature + 30 °C
Supply voltage *
230 V ± 10 % / 1 ph / 50 Hz or 400 V ± 10 % / 3 ph / 50 Hz
* Equipped with 2 motors (2 overload thermal protections are required).
* Single phase on size 35 only.
Unit in operation with hot water circulation
900 230-1-50 0.022 0.25 F 54
900 230/400-3-50 0.037 0.46 / 0.27 F 54
1400 230-1-50 0.06 0.6 F 54
1400 230/400-3-50 0.038 0.4 / 0.23 F 54
900 230/400-3-50 0.25 1.44 / 0.83 F 55
1400 230/400-3-50 0.25 1.41 / 0.81 F 55
1400/900 400-3-50 0.4 / 0.12 1.38 / 0.51 F 55
900 230/400-3-50 0.25 1.44 / 0.83 F 55
1400 230/400-3-50 0.55 2.46 / 1.42 F 55
1400/900 400-3-50 0.55 / 0.18 1.62 / 0.73 F 55
900 230/400-3-50 0.25 1.44 / 0.83 F 55
1400 230/400-3-50 0.55 2.46 / 1.42 F 55
1400/900 400-3-50 0.55 / 0.18 1.62 / 0.73 F 55
900 230/400-3-50 0.37 2.08 / 1.19 F 55
1400 230/400-3-50 0.75 3.22 / 1.86 F 55
1400/900 400-3-50 1.1 / 0.38 2.65 / 1.35 F 55
700 230/400-3-50 0.37 2.00 / 1.16 F 55
900 230/400-3-50 0.75 3.65 / 2.1 F 55
900/700 400-3-50 0.75 / 0.37 2.09 / 1.32 B 54
900 230/400-3-50 0.25 1.44 / 0.83 F 55
1400 230/400-3-50 0.55 2.46 / 1.42 F 55
1400/900 400-3-50 0.55 / 0.18 1.62 / 0.73 F 55
Current (A)
Insul.
class
IP
index
35
Sizes Speed (rpm) Voltage (V - Ph - Hz) Power (kW)
70
110 *
45
50
55
65
