Airwell Westherm 55 [7/16] Dimensional data and weight of options
![Airwell Westherm 55 [7/16] Dimensional data and weight of options](/views2/1408117/page7/bg7.png)
Page 6
5 - Dimensional Data and Weight of Options
Component description
V : Vertical mounting unit heater.
H : Horizontal mounting unit heater.
A : Cubic inlet casing for matching other accessories on 3
faces.
B : Mixing box with dampers.
C : Horizontal non-return shutter.
D : Vertical non-return shutter.
E : Filter box with flat-bank filter.
F : External weatherproof louvre with bird guard.
G : Duct.
J : Mixing box with adjustable shutter and wire mesh
guard.
K : Return air plenum with wire mesh guard.
L : Flat-bank filter for casing A.
Z : Roof air inlet with bird guard and seal ring, to be
mounted by others.
Sizes354550556570110
a
440 560 560 680 800 800 680
e
370 490 490 610 730 730 610
f
382 502 502 622 742 742 622
f
1
392 512 512 632 752 752 632
h
720 900 900 1080 1280 1280 1080 *
h
2
190 230 230 275 310 310 275
h
4
960 1080 1080 1200 1320 1320 1200
j
480 600 600 720 840 840 720
j
1
460 580 580 700 820 820 700
Dimensions (mm)
Note : The size 110 is equipped with 2 accessory sets of the
size 55. (* 1080 x 1870).
a 500
e x e
a x a
a
E
a x a
120
a x a
f x f
f1 x f1
j
a x a
120
a
E
j
1
Arrangement 1 (VAL) Arrangement 2 (VAF) Arrangement 3 (VAK)
Filter removal Filter E is optional Filter E is optional
The filter box E allows a filter removal from one of the four sides.
j
a x a
120
a
E
j
1
1440
or 940
a x a
Arrangement 5 (VAGK)
Filter E is optional
j
a x a
120
a
E
j
1
1440
or 940
a x a
f1 x f1
a x a
f x f
Arrangement 6 (VAGJF)
Filter E is optional
j
a x a
120
a
E
j
1
a x a
f1 x f1
a x a
f x f
Arrangement 4 (VAJF)
Filter E is optional
Standard arrangements
