7
Standard Motor Electrical Data
Electric Heating Coil Data
EC Motor Electrical Data
Coil Water Volume
Sizes
VH 03 VH 05 VH 07 VH 10
Absorbed
current
(A) (1)
Absorbed
power
(W) (1)
Absorbed
current
(A) (1)
Absorbed
power
(W) (1)
Absorbed
current
(A) (1)
Absorbed
power
(W) (1)
Absorbed
current
(A) (1)
Absorbed
power
(W) (1)
Fan speed
V1 0.19 42 0.24 53 0.66 132 0.68 136
V2 0.31 70 0.28 61 0.75 163 0.78 165
V3 0.46 104 0.31 69 0.82 182 0.90 195
V4 0.65 147 0.35 77 0.88 201 1.02 225
V5 0.76 172 0.41 91 0.98 222 1.12 250
V6 0.92 207 0.58 120
Sizes
VH 15 VH 18 VH 21 VH 24 VH 27
Absorbed
current
(A) (2)
Absorbed
power
(W) (2)
Absorbed
current
(A) (2)
Absorbed
power
(W) (2)
Absorbed
current
(A) (2)
Absorbed
power
(W) (2)
Absorbed
current
(A) (2)
Absorbed
power
(W) (2)
Absorbed
current
(A) (2)
Absorbed
power
(W) (2)
Fan speed
V1 0.93 180 0.93 180 0.93 180 2.00 420 2.00 420
V2 1.33 271 1.33 271 1.33 271 2.40 530 2.40 530
V3 2.00 421 2.00 421 2.00 421 3.00 673 3.00 673
V4 2.52 587 2.52 587 2.52 587 3.85 870 3.85 870
V5 3.17 675 3.17 675 3.17 675
Sizes VH 03 VH 05 VH 07 / VH 10 VH 15 / VH 18 / VH 21 VH 24 / VH 27
Capacity (W)
BE1 600 500 1000 1000 1000
BE2 800 750 1500 2000 2000
BE3 1200 1000 2000 3000 3000
BE4 1400 1500 - - -
BE5 1600 2000 - - -
Sizes
Water volume (in litres)
2-pipes
4-pipes
Cooling Heating
VH 03
0.9 0.8 0.2
VH 05 1.9 1.6 0.5
VH 07 2.3 1.9 0.6
VH 10 4.2 3.2 1.1
VH 15 3.7 3.1 1
VH 18 5.4 3.7 1.7
VH 21 6.5 5.2 1.7
VH 24 7 5.8 1.7
VH 27 8.9 7.3 1.9
(1) Absorbed current and absorbed power data given for a motor operating with 230V/1Ph/50Hz power supply, non ducted unit with 0 Pa external static pressure
and G3 filter. Inlet and outlet of duct circular.
(2) Absorbed current and absorbed power data given for a motor operating with 230V/1Ph/50Hz power supply, non ducted unit with 0 Pa external static pressure
and G3 filter. Inlet and outlet of duct rectangular.
VH03 : Max = 10V VH05 : Max = 7V VH07 : Max = 8V VH10 : Max = 8V
Max absorbed
current (A)
Max absorbed
power (W)
Max absorbed
current (A)
Max absorbed
power (W)
Max absorbed
current (A)
Max absorbed
power (W)
Max absorbed
current (A)
Max absorbed
power (W)
0.75 89 0.85 111 1.55 209 1.67 229
