8
Sound Power Levels Lw in dB(A) - VH 03
Speeds Type
Acoustical power per octave band (dB(A))
Lw global
dB(A)
Lp global
dB(A) (3)
NR (3)
125Hz 250Hz 500Hz 1kHz 2kHz 4kHz
V1
Return + Radiated (1) 39.4 41.7 42.0 41.6 40.4 31.6 48.2
27.2 21Discharge (1) 41.9 39.9 41.9 40.5 35.1 23.8 47.4
Radiated (2) 35.9 34.5 35.4 34.3 29.9 20.3 41.4
V2
Return + Radiated (1) 42.2 44.5 44.8 44.8 44.0 35.6 51.3
30.3 25Discharge (1) 43.5 42.5 44.7 44.1 40.0 27.9 50.2
Radiated
(2) 37.6 37.2 38.3 37.9 33.5 26.5 44.3
V3
Return + Radiated (1) 43.5 46.5 46.7 46.8 46.2 38.4 53.2
32.2 27Discharge
(1) 44.3 44.3 46.5 46.1 42.3 30.7 52.0
Radiated
(2) 37.4 39.2 39.9 39.4 35.5 28.2 45.6
V4
Return + Radiated (1) 44.9 47.9 48.1 48.4 48.3 40.6 54.9
33.9 29Discharge
(1) 45.2 45.9 48.0 48.2 44.4 33.4 53.7
Radiated (2) 40.0 39.8 41.0 40.8 37.4 30.3 47.0
V5
Return + Radiated (1) 46.2 49.6 49.2 50.0 50.0 42.6 56.4
35.4 31Discharge
(1) 46.5 47.9 49.7 50.2 46.8 35.9 55.5
Radiated
(2) 38.7 41.9 42.4 42.2 39.2 32.4 48.2
V6
Return + Radiated (1) 48.2 51.0 50.5 51.2 51.2 44.1 57.7
36.7 32Discharge
(1) 50.0 49.6 51.4 52.2 48.7 38.2 57.6
Radiated
(2) 40.6 43.2 43.8 43.7 40.9 34.4 49.8
Speeds Type
Acoustical power per octave band (dB(A))
Lw global
dB(A)
Lp global
dB(A) (3)
NR (3)
125Hz 250Hz 500Hz 1kHz 2kHz 4kHz
V1
Return + Radiated (1) 30.0 35.6 36.0 35.8 29.9 17.1 41.3
20.3 15Discharge (1) 29.6 34.1 30.5 34.3 32.2 13.4 39.5
Radiated (2) 19.4 25.5 27.2 27.5 21.6 13.5 32.3
V2
Return + Radiated (1) 34.6 42.3 42.6 44.9 40.8 28.7 49.1
28.1 24Discharge (1) 34.8 40.1 38.3 41.7 41.2 26.2 46.9
Radiated (2) 30.9 32.3 34.8 37.2 31.9 17.3 41.1
V3
Return + Radiated (1) 38.8 48.3 48.1 52.6 49.4 40.3 56.2
35.2 31Discharge
(1) 40.1 46.3 45.2 51.0 49.4 38.6 54.9
Radiated
(2) 30.4 38.5 40.0 45.1 40.3 30.7 48.0
V4
Return + Radiated (1) 42.5 52.3 53.4 58.5 56.8 48.5 62.2
41.2 37Discharge (1) 45.7 52.4 51.9 57.2 55.6 46.4 61.2
Radiated
(2) 34.5 44.3 46.1 51.4 48.1 40.4 54.5
V5
Return + Radiated (1) 45.8 54.9 56.1 60.8 60.4 52.4 65.1
44.1 41Discharge
(1) 48.0 55.5 55.0 60.2 59.2 50.7 64.4
Radiated (2) 37.4 46.5 48.5 53.0 51.0 43.6 56.7
V6
Return + Radiated (1) 52.3 56.9 62.5 63.9 63.6 55.9 68.8
47.8 44Discharge (1) 50.7 58.9 58.5 62.7 64.0 54.1 68.0
Radiated (2) 39.6 48.5 50.7 54.4 54.0 46.5 58.9
(1) According Eurovent 8/2, data given for a unit with :
- 50 Pa external static pressure in medium speed (V3),
- circular return and discharge,
- G3 standard filter.
(2) Data given for a unit with :
- 50 Pa external static pressure in medium speed (V3),
- circular return and discharge,
- ducted return and discharge (1.5 m),
- G3 standard filter.
(3) Informative data, considering an hypothetical sound attenuation of the room and installation of 21dB.
(1) According Eurovent 8/2, data given for a unit with :
- 50 Pa external static pressure in medium speed (V3),
- circular return and discharge,
- G3 standard filter.
(2) Data given for a unit with :
- 50 Pa external static pressure in medium speed (V3),
- circular return and discharge,
- ducted return and discharge (1.5 m),
- G3 standard filter.
(3) Informative data, considering an hypothetical sound attenuation of the room and installation of 21dB.
Sound Power Levels Lw in dB(A) - VH 05
