![Airwell Wespak 1.39 [12/18] Electrical connections cont d](/img/pdf.png)
Airwell Wespak 1.39 [12/18] Electrical connections cont d
![Airwell Wespak 2.69 [12/18] Electrical connections cont d](/views2/1408180/page12/bgc.png)
10
7 - Electrical Connections (cont'd)
CMVM fan speed selector switch
FMA
FIELD WIRING
FACTORY WIRING
EARTH
NEUTRAL
LIVE
Earth Yellow/Green
Neutral Blue
LS Red
MS Violet
HS Black
230/1/50
SUPPLY VOLTAGE
FMA Fan motor assembly
M Electrical junction block
R Relay
LS Low speed
MS Medium speed
HS High speed
HS
MS
LS
