Airwell Wespak 1.39 [7/18] Dimensional data and weight cont d
![Airwell Wespak 1.39 [7/18] Dimensional data and weight cont d](/views2/1408180/page7/bg7.png)
5
English
4 - Dimensional Data and Weight (cont'd)
4.1 - Dimensional Data (cont'd)
Modules : VP1, VP6, VP7, VM80, VM90
320
370
740
A
B
2525
90
C
30
185
51
90
32025
Minimum space for
servicing
Hole provision for
electric power supply
Modules : VM39, VM49, VM59
370
1110
A
B
51
30
90
C
185
90
320 2532025
Modules : VM19, VM69, VM79
370
A
B
51
30
90
C
185
90
320 25
Dimensions in mm.
MODELS 1.39 2.69 3.99
A 582 970 1320
B 762 1150 1500
C 779 1167 1517
Minimum space for
servicing
Hole provision for
electric power supply
Hole provision for
electric power supply
Minimum space for
servicing
740 (arrangement VM69)
1110 (arrangement VM19 and VM79)
