Airwell Wespak 1.39 [6/18] Dimensional data
![Airwell Wespak 1.39 [6/18] Dimensional data](/views2/1408180/page6/bg6.png)
4
4 - Dimensional Data and Weight
4.1 - Dimensional Data
Modules : 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, HM8, HM9, VM8, VM9
320
370
370 A
B
51 90
2525
185
90
C
30
Minimum space for
servicing
Hole provision for
electric power supply
Modules: HM49, HM59, HM69, HM79
320
370
740
A
B
90
25
C
185
51
90
30
Minimum space for
servicing
Hole provision for
electric power supply
Modules: HP4, HP5, HP6, HP7. HM80, HM81, HM83, HM90, HM91, HM92, HM93, MFP, PAS
320
370
740 A
B
51 90
2525
185
90
C
30
Minimum space for
servicing
Dimensions in mm.
MODELS 1.39 2.69 3.99
A 582 970 1320
B 762 1150 1500
C 779 1167 1517
Hole provision for
electric power supply
