APPENDIX / ANNEXE / ANLAGE / ALLEGATO / ANEXO
XVIII
MODEL NOMENCLATURE
NOMENCLATURE DES APPAREILS
BEZEICHNUNG DER GERÄTE
NOMENCLATURA – DESCRIZIONE DEGLI APPARECCHI
NOMENCLATURA
REP.
MODEL TAILLES GRÖSSEN MISURE TAMAÑOS
A10
MODEL 10 MODELE 10 MODELL 10 MODELLO 10 MODELO 10
A20
MODEL 20 MODELE 20 MODELL 20 MODELLO 20 MODELO 20
A30
MODEL 30 MODELE 30 MODELL 30 MODELLO 30 MODELO 30
A40
MODEL 40 MODELE 40 MODELL 40 MODELLO 40 MODELO 40
A50
MODEL 50 MODELE 50 MODELL 50 MODELLO 50 MODELO 50
A60
MODEL 60 MODELE 60 MODELL 60 MODELLO 60 MODELO 60
A70
MODEL 70 MODELE 70 MODELL 70 MODELLO 70 MODELO 70
A80
MODEL 80 MODELE 80 MODELL 80 MODELLO 80 MODELO 80
A90
MODEL 90 MODELE 90 MODELL 90 MODELLO 90 MODELO 90
MOUNTING MONTAGE MONTAGE MONTAGGIO MONTAJE
W
CONSOLE MOUNTING MONTAGE ALLEGE MURAL WANDMONTAGE MIT
STÜTZMAUER
MONTAGGIO DAVANZALE
MURALE
MONTAJE ALFEIZAR MURAL
H
HORIZONTAL CEILING
MOUNTING
MONTAGE PLAFONNIER
HORIZONTAL
HORIZONTALE
DECKENMONTAGE
MONTAGGIO PLAFONIERA
ORIZZONTALE
MONTAJE DE TECHO
HORIZONTAL
WITH CASING / WITHOUT
CASING
HABILLAGE / MODELE NU
GEHÄUSE / MODELL OHNE
VERKLEIDUNG
RIVESTIMENTO / MODELLO
NON RIVESTITO
REVESTIMIENTO/MODELO
NO EQUIPADO
N
MODEL WITHOUT CASING MODELE NU MODELL OHNE VERKLEIDUNG MODELLO NON RIVESTITO MODELO NO EQUIPADO
C
MODEL WITH CASING MODELE CARROSSE MODELL MIT VERKLEIDUNG MODELLO CAROZZATO MODELO CON ENVOLVENTE
BRAND MARQUE COMMERCIALE HANDELSMARKE MARCA COMMERCIALE MARCA COMERCIAL
MARQUE
INDICATES BRAND
INDIQUE LA MARQUE
COMMERCIALE
ZEIGT DIE HANDELSMARKE AN INDICA LA MARCA
COMMERCIALE
INDICA LA MARCA COMERCIAL
$
NO BRAND SANS MARQUE OHNE MARKE SENZA MARCA SIN MARCA
COLD WATER / HOT WATER
COIL
BATTERIES EAU FROIDE /
EAU CHAUDE
KALTWASSER- /
HEISSWASSER-SATZ
BATTERIE ACQUA FREDDA /
ACQUA CALDA
BATERÍAS AGUA FRÍA /
AGUA CALIENTE
20
2P/2R COIL BATTERIE 2T/2R KÜHLER 2T/2R BATTERIA 2T/2R BATERÍA 2T/2R
30
2P/3R COIL BATTERIE 2T/3R KÜHLER 2T/3R BATTERIA 2T/3R BATERÍA 2T/3R
21
4P/2R+1R COIL BATTERIE 4T/2R+1R KÜHLER 4T/2R+1R BATTERIA 4T/2R+1R BATERÍA 4T/2R+1R
31
4P/3R+1R COIL BATTERIE 4T/3R+1R KÜHLER 4T/3R+1R BATTERIA 4T/3R+1R BATERÍA 4T/3R+1R
2E
2P/2R COIL + ELECTRIC
HEATER
MODEL A10-A80-A90
2T/2R BATTERIE + CHAUFFAGE
ELECTRIQUE
TAILLE A10-A80-A90
2T/2R KÜHLER +
ELEKTROHEIZUNGEN
GRÖSSE A10-A80-A90
2T/2R BATTERIA +
RISCALDAMENTO ELETTRICO
MISURA. A10-A80-A90
2T/2R BATERÍA +
CALEFACCIÓN ELÉCTRICA
TAMAÑO A10-A80-A90
3E
2P/3R COIL + ELECTRIC
HEATER
MODEL A10-A80-A90
2T/3R BATTERIE + CHAUFFAGE
ELECTRIQUE
TAILLE A10-A80-A90
2T/3R KÜHLER +
ELEKTROHEIZUNGEN
GRÖSSE A10-A80-A90
2T/3R BATTERIA +
RISCALDAMENTO ELETTRICO
MISURA. A10-A80-A90
2T/3R BATERÍA +
CALEFACCIÓN ELÉCTRICA
TAMAÑO A10-A80-A90
