APPENDIX / ANNEXE / ANLAGE / ALLEGATO / ANEXO
XXII
REP.
OPTIONS OPTIONS OPTIONEN OPZIONI OPCIONES
RD
FRONT AIR INTAKE REPRISE EN FACADE ANSAUG FRONTSEITIG RIPRESA IN FACCIATA RETORNO EN CARA FRONTAL
RF
FRONT AIR INTAKE ASSY (CAR) ENS/REPRISE FACADE (CAR) SATZ/ANSAUG FRONTSEITIG
(CAR)
INS/RIPRESA FACCIATA (CAR) CONJUNTO/RETORNO CARA
FRONTAL (CAR)
RFAMOV
REMOVABLE FRONT AIR INTAKE
ASSY
ENS/REPRISE FACADE
AMOVIBLE
SATZ/ANSAUG FRONTSEITIG
ABNEHMBAR
INS/RIPRESA FACCIATA
AMOVIBILE
CONJUNTO/RETORNO CARA
FRONTAL EXTRAÍBLE
CRG
AIR OUTLET AIR FRAME CADRE REFOULEMENT AU
SOUFFLAGE
DRUCKSEITIGER RAHMEN AM
AUSBLAS
TELAIO MANDATA AL
SOFFIAGGIO
MARCO DESCARGA EN LA
IMPULSIÓN
PF
PF1
PF2
FUSE HOLDER PORTE FUSIBLE SICHERUNGSHALTER PORTA FUSIBILE PORTAFUSIBLES
C/O
MECHANICAL CHANGE OVER
(cycle inversion)
SONDE MECANIQUE.CHANGE
OVER (inversion cycle)
MECHANISCHER MESSFÜHLER.
UMSCHALTER (Zyklusumkehr)
SONDA MECCANICA.CHANGE
OVER (inversione ciclo)
SONDA MECÁNICA. CHANGE
OVER (inversión ciclo)
BAC
AUXILIARY TRAY BAC AUXILIAIRE HILFSWANNE VASCA AUSILIARE DEPÓSITO AUXILIAR
ALV
REAR CASING PANEL PANNEAU HABILLAGE ARRIERE HINTERE GEHÄUSEPLATTE PANNELLO RIVESTIMENTO
POSTERIORE
PANEL REVESTIMIENTO
TRASERO
PRC
CONDENSATE LIFT PUMP POMPE RELEVAGE
CONDENSATS
KONDENSWASSERHEBEPUMPE POMPA SOLLEVAMENTO
CONDENSATI
BOMBA ELEVACIÓN
CONDENSADOS
RCL
REMOTE CONTROL
TELECOMMANDE FERNBEDIENUNG TELECOMANDO MANDO A DISTANCIA
NIU
µBMS/RCW2 REMOTE
CONTROL INTERFACE
INTERFACE TELECOMMANDE
µBMS/RCW2
SCHNITTSTELLE
FERNBEDIENUNG µBMS/RCW2
INTERFACCIA TELECOMANDO
µBMS/RCW2
INTERFAZ MANDO A
DISTANCIA µBMS/RCW2
eNIU
(AIRCONET/MODBUS)
INTERFACE
INTERFACE (AIRCONET/
MODBUS)
SCHNITTSTELLE (AIRCONET/
MODBUS)
INTERFACCIA (AIRCONET/
MODBUS)
INTERFAZ (AIRCONET/
MODBUS)
SEH
CHANGE OVER SENSOR SONDE CHANGE OVER MESSFÜHLER UMSCHALTER SONDA CHANGE OVER SONDA CHANGE OVER
REL/CH
HEATING RELAY RELAIS CHAUFFAGE
RELAIS HEIZUNG RELÉ RISCALDAMENTO RELÉ CALEFACCIÓN
