APPENDIX / ANNEXE / ANLAGE / ALLEGATO / ANEXO
XXIII
A40.W.C.$.30.1000W.V1.V2.V4.G.G1.B.4V/TOR/2T.MPG.+ALV
A40: MODELE 40
W: MONTAGE ALLEGE MURAL
C: MODELE CARROSSE
$: SANS MARQUE
30: BATTERIE 2T/3R
1000W: PUISSANCE CANNE CHAUFFANTE EN W
V1.V2.V4: VITESSES CABLEES
G: FACE DE SERVICE GAUCHE
G1: FILTRE A AIR STANDARD
B: BORNIER
4V/TOR/2T: VANNE 4 VOIES / TOUT OU RIEN / 2 TUBES
MPG: PIEDS+GRILLE
ALV
: PANNEAU HABILLAGE ARRIERE
A40: MODEL 40
W: CONSOLE MOUNTING
C: MODEL WITH CASING
$: NO BRAND
30: 2P/3R COIL
1000W: HEATING CAPACITY IN W
V1.V2.V4: SPEED CONFIGURATION
G: SERVICE SIDE (LEFT)
G1: STANDARD AIR FILTER
B: TERMINAL BLOCK
4V/TOR/2T: 4-WAY VALVE / OPEN-CLOSE / 2 PIPES
MPG: FEET+GRILLE
ALV: REAR CASING PANEL
A40: MODELLO 40
W: MONTAGGIO DAVANZALE MURALE
C: MODELLO CAROZZATO
$: SENZA MARCA
30: BATTERIA 2T/3R
1000W: POTENZA CANNA RISCALDANTE IN W
V1.V2.V4: CONFIGURAZIONE DELLE VELOCITÀ
G: PANNELLO DI SERVIZIO SINISTRA
G1: FILTRO D’ARIA STANDARD
B: MORSETTIERA
4V/TOR/2T: VALVOLA 4 VIE / TUTTO O NULLA / 2 TUBI
MPG: PIEDINI+GRIGLIA
ALV: PANNELLO RIVESTIMENTO POSTERIORE
A40: MODELL 40
W: WANDMONTAGE MIT STÜTZMAUER
C: MODELL MIT VERKLEIDUNG
$: OHNE MARKE
30: KÜHLER 2T/3R
1000W: LEISTUNG HEIZROHR IN W
V1.V2.V4: KONFIGURATION DER DREHZAHLEN
G: WARTUNGSSEITE LINKS
G1: STANDARD LUFTFILTER
B: KLEMMENLEISTE
4V/TOR/2T: 4-WEGE-VENTIL / ALLES ODER NICHTS / 2 LEITUNGEN
MPG: FÜSSE+GITTER
ALV: HINTERE GEHÄUSEPLATTE
A40: MODELO 40
W: MONTAJE ALFEIZAR MURAL
C: MODELO CON ENVOLVENTE
$: SIN MARCA
30: BATERÍA 2T/3R
1000W: POTENCIA CALENTADOR EN W
V1.V2.V4: CONFIGURACIÓN DE VELOCIDADES
G: CARA DE SERVICIO IZQUIERDA
G1: FILTRO DE AIRE ESTÁNDAR
B: CAJA DE BORNES
4V/TOR/2T: VÁLVULA 4 VÍAS/TODO O NADA/2 TUBOS
MPG: PATAS + REJILLA
ALV: PANEL REVESTIMIENTO TRASERO
EXAMPLE
EXEMPLE
BEISPIEL
ESEMPIO
EJEMPLO
