Page 9
AQH sizes 202530354050607080
Power supply (V / Ph / Hz)
Cooling capacity (1) kW 21.5 26 29.9 34.2 39.5 47.9 55.9 67 75
Heating capacity (2) kW 23.1 28 32.9 37.4 45 56 65 78 84.9
Total power consumption with pump (3) kW 8.4 10 11.4 12.2 16.1 19.4 23.9 28.1 30.7
Total power consumption (3) kW 7.6 9.2 10.6 11.4 15.4 18.7 22.8 27 29.6
Total power consumption with pump (4) kW 8.6 10 11.4 11.4 16.4 19.4 24.2 28.6 31.5
Total power consumption (4) kW 7.8 9.2 10.6 10.6 15.6 18.6 23.1 27.5 30.4
COP 3.1 3.1 3.1 3 2.8 2.7 2.7 2.7 2.7
Refrigerant charge kg 6.4 6.4 6.4 7.6 9 11.5 13 14 16
Lw sound power levels dB(A) 75 76 76 77 82 82 84 87 87
Compressors
Type
Quantity 222222222
Capacity reduction stages 2 2 2 2 2 2 2 2 2
Minimum capacity %505050504536364550
Safety pressostat
Evaporator
Type
Maximum pressure refrigerant side bar
Maximum pressure water side bar
Safety
Anti-freeze protection heating resistance 1 1 1 1 1 1 1 1 1
Water volume litres 1.67 2.2 2.44 2.44 3.44 4.33 5.33 6.33 7.10
Condenser
Type
Fans
Quantity 222211111
Fan diameter mm 610 610 610 610 800 800 800 800 800
Speed (High/Low) rpm 640/500 640/500 640/500 640/500 700/500 700/500 700/500 900/520 900/520
Max. air flow (HS) m
3
/h 11200 11200 11200 11200 15500 15500 15500 21000 21000
Water connections
Type
Diameter inches 1"1/2 1"1/2 1"1/2 1"1/2 2" 2" 2" 2" 2"
Expansion tank litres
Filter
Safety valve calibration bar333333333
Water circulation pump
Type
Material
Protection index
Three phase motor
Weight
With pump kg 286 296 306 305 510 585 590 620 640
Without pump kg 271 281 291 290 490 565 570 600 620
Dimensions
Length mm 1477 1477 1477 1477 1737 2168 2168 2168 2168
Width mm 516 516 516 516 1201 1201 1201 1201 1201
Height mm 1607 1607 1607 1607 1634 1634 1634 1634 1634
400/3+N/50
Scroll - Hermetically sealed
HP (fixed set point)
LP transducer
HP transducer
Brazed stainless steel plates
30
10
Water flow switch
3/8" copper tube - Louvred aluminium fins
Gas - Threaded
Differential pressostat
Gas - Threaded
12
2", supplied fitted
5
1" 1/2, supplied loose
Class F
Single speed centrifugal pump
Composite
IP54
AISI 304 stainless steel
IP54
Class F
(1) Values based on chilled water inlet/outlet temperatures of 12/7° C and an ambient air temperature of 35° C.
(2) Values based on hot water inlet/outlet temperatures of 40/45 °C and an ambient air temperature of 7 °C.
(3) Cooling mode data.
(4) Heating mode data.
Technical characteristics - HFC 407C
