Page 12
Physical Data SLH 1202 to 2202 - ELN Version
(1) Data based on leaving chilled water temperature of 7 °C and ambient air temperature of 35 °C.
(2) Data based on leaving hot water temperature of 45 °C and ambient air temperature of 7 °C/88 % HR.
(3) Data given for compressors only.
(4) Sound levels given at fully loaded conditions. Sound power level values refer to ISO 3744 and Eurovent 8/1.
(5) Sound pressure level values refer to ISO 3744.
SLH ELN models 1202 1402 1602 1802 1902 2002 2202
Nominal cooling capacity (1) kW 246.5 276.0 315.3 339.8 375.6 403.1 428.3
Power input (3) kW 108.2 116.7 131.7 146.0 158.8 164.0 188.6
EER 2.3 2.4 2.4 2.3 2.4 2.5 2.3
Nominal heating capacity (2) kW 278.4 300.2 341.7 372.8 421.4 457.5 465.2
Power input (3) kW 96.3 105.9 118.8 132.3 140.9 155.9 159.9
COP 2.9 2.8 2.9 2.8 3.0 2.9 2.9
Number of refrigerant circuits 2222222
Number of capacity steps
Compressors
Number 2222222
Type
Evaporators
Number 1111111
Type
Water content per evaporator litres 26 26 33 40 40 40 50
Condensers
Number of coils 4444444
Face area per coil m
2
4444666
Number of rows 3444334
Fans
Number of fans 66888108
Nominal fan speed rpm 500 500 500 550 500 500 500
Total air flow m
3
/h 67 000 62 000 75 000 81 900 91 500 108 400 89 000
Total power kW 7.5 7.5 10.0 10.0 10.0 12.5 10.0
Weight
Shipping weight kg 3610 4160 4270 4280 5440 5880 5850
Operating weight kg 3636 4186 4303 4320 5480 5920 5900
Sound levels
Sound power levels (4) dB(A) 88.3 88.3 88.7 88.7 88.7 88.7 88.7
Sound pressure levels at 10 m (5) dB(A) 56.0 56.0 57.0 57.0 57.0 57.0 57.0
Dimensions
Length mm 4030 4030 4030 4030 6030 6030 6030
Width mm 2200 2200 2200 2200 2200 2200 2200
Height mm 2550 2550 2550 2550 2550 2550 2550
6
Twin screw
Plate
