LOGICOOL Chillers

General Description

STANDARD FEATURES - GENERAL

Refrigeration

Each refrigeration circuit is supplied with the following:

• Full operating charge of R410A

• Electronic Expansion Valve (EEV)

• Liquid line ball valve

• Discharge line ball valve

• Liquid line filter drier

• Liquid line sight glass

• Low pressure switch with manual reset via microprocessor controller

• High pressure switch with manual reset

• Suction and liquid pressure transducers

• Valves for refrigeration head pressure control

Water / Glycol

Each water glycol circuit is supplied with the following:

• 3 way modulating valve to control free-cooling operation

• Strategically placed automatic air vents

• Strategically placed drain valves

• Ball valve(s) for Free-cooling coil isolation to allow for maintenance

• Pressure transducer(s) across evaporator to monitor water pressure drop

• Inlet water filter ball valve 20 mesh

Flushing Bypass Kit

Comprises:

(Standard)

• Shut off valves

Factory fitted to protect the evaporator from clogging by sediment and to enable the

system to be purged before running.

Controls

As standard, the microprocessor controller can provide modulating

capacity control.

Optionally, the controller is designed to provide capabilities for;

• Building Management Systems

to meet all your system requirements, please confirm at time of order.

For further details, refer to Controls.

Evaporator Differential

Pressure Sensor

Facilitates low flow limiting and pressure drop monitoring via the microprocessor.

Measures the evaporator pressure drop which in turn enables the evaporator flow rate to

be calculated.

Chillers

Installation & Maintenance : 6560544 A 06/07
