Chillers LOGICOOL
General Description
STANDARD FEATURES - GENERAL
Electrical
Dedicated weatherproof electrical power and controls panels are situated at the front of
the unit and contain:
• Separate, fully accessible, controls compartment
• Circuit breakers for protection of all major unit components
• Separate, permanent supply for controls/trace heating, 230V / 50Hz / 1Ph
CAUTION
A fused and isolated electrical supply of the appropriate phase, frequency and
voltage should be installed.
The electrical power and control panel is wired to the latest European standards and
codes of practice.
Mains supply is 3 phase and a neutral is not required. Refer to Interconnecting Wiring.
Electrical terminals for external evaporator pipework trace heating (240V/500W)
are provided.
OPTIONAL EXTRAS - ENERGY SAVING
Electronic Soft Start
The electronic soft start enables the chiller compressor motor to be ramped to speed with
the minimum full load current. Further benefits include removal of nuisance tripping,
supply voltage dips and motor overheating.
Electronically
Commutated (EC) Fan
Motor
Sickle bladed fan assemblies with integral long bellmouth and fingerproof grille.
Incorporate external EC rotor motor technology, to provide highly accurate discreet speed
control, discharge air vertically. The fans offer maximum airflow performance while
keeping sound levels to a minimum.
Each fan incorporates on board electronics with inverter-driven DC motor control,
responding to a signal from the unit microprocessor.
For further details, please refer to Technical Manual.
OPTIONAL EXTRAS - GENERAL
Loose Item
- Instructions supplied with item
• Anti Vibration Mounts
Factory Fitted
• Corrosion Resistant Coated Coils
• BMS Interface Card
• Leak Detection System
• Remote Setpoint Adjust
• Flushing Bypass Kit (Incl. Shut off & Water Regulating Valve)
• Integral Pump Packages
• Compressor Oil Heater
• Expansion Vessel
• Alternative Refrigerant (Outside EU)
OPTIONAL UNIT COVER
• Commissioning
For details and a competitive quotation,
contact Airedale Service.
• Chillerguard® Maintenance
(1)
(1) UK Mainland Sites
11
Chillers
Installation & Maintenance : 6560544 A 06/07
