Installation & Maintenance : 903-126 IM E 10/04/A

Installation Data

The installation position should be selected with the following points in mind:

• Position on a stable and even base, levelled to ensure that the compressor

operates correctly.

• Levelling should be to +/- 5mm

• Where vibration transmission to the building structure is possible, fit spring anti-

vibration mounts and flexible water connections.

• Observe airflow and maintenance clearances.

• Pipework and electrical connections are readily accessible.

POSITIONING

• Where multiple units are installed, due care should be taken to avoid the

discharge air from each unit adversely affecting other units in the vicinity.

CAUTION

Prior to connecting services, ensure that the equipment is installed and

completely level.

500

Controls

Panel

Inlet /

Outlet

Model Size ABC

UWC 75 – 125 mm 1800 760 760

UWC 150 – 250 (Ex. 240) mm 2000 760 760

UWC 240 – 450 (Ex. 250) mm 3200 900 900
