Airedale UWC 75 [6/42] Ultima water cooled chillers
![Airedale UWC 75 [6/42] Ultima water cooled chillers](/views2/1409533/page6/bg6.png)
ULTIMA WATER COOLED Chillers
Chillers
6
Installation & Maintenance : 903-126 IM E 10/04/A
General Description
WATER COOLED LIQUID CHILLER
UWC Ultima Water Cooled Chiller
75 – 450
Model Size (Expressed as Nominal Cooling in kW)
D Double Circuit - Standard Chiller
DQ Double Circuit - Quiet Chiller
DSQ Double Circuit - Super Quiet Chiller
UNIT IDENTIFICATION
Example UWC250DQ
The Airedale range of Ultima Water Cooled liquid chillers covers the nominal capacity
range 75kW to 450kW in 45 model sizes incorporating Standard D, Quiet DQ and
Super Quiet DSQ variations.
Attention has been placed on maximising the unit’s performance while keeping the sound
and vibration levels and footprint to an absolute minimum.
The range has been specifically designed for plant room installations.
INTRODUCTION
A matching range of Dry Cooler units is available to complement the Water Cooled Liquid
Chiller, please refer to Airedale.
Airedale certify that the equipment detailed in this manual conforms with the following
EC Directives:
Electromagnetic Compatibility Directive (EMC)
89/336/EEC
Low Voltage Directive (LVD)
73/23/EEC
Machinery Directive (MD)
89/392/EEC in the version 98/37/EC
Pressure Equipment Directive (PED)
97/23/EC
CE DIRECTIVE
To comply with these directives appropriate national & harmonised standards have been
applied. These are listed on the Declaration of Conformity, supplied with each product.
REFRIGERANTS
The range has been designed and optimised for operation with the ozone benign
R407C refrigerant.
STANDARD FEATURES
The Standard Ultima Water Cooled Chiller comes complete with:
•
Microprocessor Control
• Evaporator Pad Heater
• Multiple Scroll Compressors
• Plate Evaporator
• Plate Condenser(s)
• Dual Independent Refrigeration Circuits
• Electronic Expansion Valve(s)
• Connections for External Trace Heating (240V/500W available)
Standard Chiller
- D
• A set of 4 M24 collared eye bolts to BS4278
With the benefits of the Standard range, the Quiet chiller is supplied with an acoustic
package, which incorporates:
Quiet Chiller
- DQ
• Compressor enclosure lined with Acoustic material
Super Quiet Chiller
- DSQ
With the benefits of the Standard range, the Super Quiet chiller is supplied with a Quiet
acoustic package, which incorporates the following to become one of the quietest
chillers available:
• Compressor enclosure lined with 40mm Acoustic material
