Please carefully read the installation instruction.
●
Illustrations of cabinet dimensions andinstallation position of the dishwasher
Prepar ations shou ld b e m ade b efore m oving the dish was her to th e ins tallation pla ce.
C hoo se a place ne ar th e si nk to fac ilitat e the inst all ation of in let a nd d rain hoses
( see figu re 1).
If di shwasher is install ed at t he corner o f th e cab in et, th ere sh ould b e som e sp ace
(illustratedin figure 2) when the door is opened.
2
1
Minimum space when
the do or is opened
【】Figure2
Cabinet dimensions
【】Figure1
Cabinet
Dishwasher
Do or of
dishwasher
Minimum space of 50mm
1
The aesthetic wooden panel could be p rocessed accor ding to the Figure 3.
The aes the t ic p a nel sh oul d
be proces se d i n a cc or dan ce
with the illustrated dimensions
【】Fig ure 3
●
Aesthetic panel's dimensions and installation
Less than 5mm
between th e top
of dis hwasher and
cabinet and the
outer door aligned
to cabinet.
90 °
90 °
600 mm
820mm
100
580mm
80
Space betw een cabinet
bottom and floor
Electrical, drain and
water su pply line
entrances
(Unit: mm)
