Bomann gspe 877 [22/30] Dishwasher installation steps
![Bomann gspe 877 [22/30] Dishwasher installation steps](/views2/1410004/page22/bg16.png)
19
Dishwasher installation steps
1
2
.
3.
4.
5.
6
7
8
Instal l the furniture door to the outer door o f the dishwasher using the brack ets provi ded. Refer
to the templa te for posi tioning of t he brackets.
Adjust the tension of the door springs by us ing an Allen key tu rning in a clockwise motion t o
tighten the le ft and ri ght doo r springs . Fai lure to do this could cause damag e to you r dishw asher
(Illustration 2)
Connect the inlet hos e to the cold wat er supply
Connect the drain hose. Refer to diagram (Figure 6)
Connect the power cord
Affix the condensation strip under the wor k surf ace of cab inet. Please ensure the conden sation
strip is flush with e dge of work surface.
Place the dishwas her into pos ition.(Illustration 4)
Level the dishwashe r. The r ear fee t can be adjust ed fro m the front of the dis hwash er by turn ing
the Al len screw in the middl e of the base of dishwasher use an A llen key (Illustration 5A). To a djust
the front feet, use a flat screw driv er and turn the fro nt feet until t he di shwasher i s level (Illustra tion 5B).
9 The dishwasher must be secured in place. There are two ways to do this:
A. N ormal work surface:Put the inst allati on hook into the slot of the s ide plane and secure it to t he
work s urface with t he wood s crews (I llustration 6).
B. M arble or granit e w ork top:Fix t he side wi th Screw. (Ill ustration 7).
【】Figure 7
