10
On-screen menu
The On-screen menu enables you to customize this unit
to suit your requirements.
1 Press ON SCREEN on the remote control.
➜ The On-screen menu appears on the screen.
2 Press v w t u to navigate the On-screen menu and to
change the settings.
3 Press ON SCREEN to exit from the On-screen menu.
Features
Dimmer
Adjusts the brightness of the front panel display.
You can use this function if the brightness of the front
panel display disturbs your enjoyment of the home
theater.
Choices: Low, Medium, Normal
Initial setting: Normal
Wake-up timer
Turns on the player from standby mode after a preset
amount of time. The timer is then reset to zero. You can
set the timer for up to 600 minutes.
Choices: 0 to 600 minutes
Initial setting: 0
Status window
Displays the current status of the player. Select [Off] to
suppress display of the Status window.
Choices: On, Off
Initial setting: On
Adv. picture
Allows you to fine-tune the following video parameters.
4:3 Aspect
You can adjust the aspect ratio of the projected images
on the screen. This function is available for progressive
scan output only.
Select [NL Stretch] for display of 4:3 image on the 16:9
screen with non-linear stretching (Center position of
screen is stretch less than the side).
Select [4:3 Pillar Box] to display 4:3 image on the 16:9
screen without stretching.
No aspect ratio adjustment is made when [AUTO] is
selected.
We recommend setting the aspect ratio on your TV if the
function is available.
Choices: 4:3 Pillar Box, NL Stretch, Auto
Initial setting: Auto
TrueLife
Produces more dynamic picture by increasing the picture
contrast and the color intensity. This function is available
for progressive scan output only.
Choices: 0 to +7
Initial setting: 0
DCDi
DCDi (Directional Correction Deinterlacing) computes
and tracks the angle of the screen edge to fill in the
missing pixel on the TV screen. DCDi will optimize the
image quality significantly, especially during the slow
motion playback. This function is available for progressive
scan output only.
Choices: On, Off
Initial setting: On
Chroma Delay
The chroma (color) and luminance (brightness) signals
are not synchronized. The Chroma Delay setting allows
you to adjust the advance delay of the chroma signal to
yield a perfectly clear picture. This function is available for
signals output from COMPONENT VIDEO OUT only.
Choices: –3 to +3
Initial setting: 0
Gamma
Enables you to adjust the intensity of the picture non-
linearly. A positive value enables you to bring out low
level detail in dark scenes, while a negative value
emphasizes contrast. This function is available for signals
output from COMPONENT VIDEO OUT only.
Choices: –7 to +7
Initial setting: 0
Video shift
Adjusts the position of the image on the screen by
scrolling it to the left or right.
Choices: +1 to +7
Initial setting: +4
General operation
Preferences
Preferences
Toolbar
Setup
Toolbar
View
Program
Play Option
Search
Slide Show
