11
English
On-screen menu
Saturation
Adjusts the video color saturation. This function is not available
for signals output from COMPONENT VIDEO OUT.
Choices: –7 to +7
Initial setting: 0
Contrast
Accentuates bright and dark parts of the video. This
function is not available for signals output from
COMPONENT VIDEO OUT.
Choices: –7 to +7
Initial setting: 0
Picture Mode
Adjusts the color tone to suit your preference and the
playing source. [Personal] will be chosen automatically
when you change the value in the following menus;
[Saturation], [Contrast], [Brightness], and [Sharpness].
This function is not available for signals output from
COMPONENT VIDEO OUT.
Choices: Rich, Natural, Soft, Animation, Personal
Initial setting: Natural
Brightness
Adjusts the overall brightness of the picture. This function
is not available for signals output from COMPONENT
VIDEO OUT.
Choices: –7 to +7
Initial setting: 0
Sharpness
Adjusts the sharpness of the video. This function is not
available for signals output from COMPONENT VIDEO OUT.
Choices: –7 to +7
Initial setting: 0
Sound
Karaoke Vocal
Enables you to play multi-channel karaoke DVDs. The
karaoke channels on the disc will be mixed into normal
stereo when you choose On.
Choices: On, Off
Initial setting: Off
Note:
– If you select [Multi-channel] in the [Analog output] menu,
the MIXED 2CH jacks do not output the downmixed
stereo.
ClearVoice
Increases the relative volume of dialog for easy listening
at night. This function is available for only certain multi-
channel discs.
Choices: On, Off
Initial setting: Off
Night Mode
When set to [On], the dynamics of the sound output is
optimized. High volume output is softened, enabling you
to watch your favorite action movie without disturbing
others.
Choices: On, Off
Initial setting: Off
CD Up-sampling
Allows you to upgrade a CD from 44.1 kHz / 16 bit to a
higher sampling rate for superior sound quality.
Choices: On, Off
Initial setting: Off
Note:
– If you select [Multi-channel] in the [Analog output] menu,
this function will not be performed.
Program
You can create your own playlist using this menu. First, go
to [Tracks], then select the tracks/chapters, etc. to include
in your playlist. The programmed playlist will be activated
when you choose [On] in the [Program] menu.
Clear all
Deletes all Programmed contents.
Program
Set the FTS program playback on or off.
Choices: On, Off
Initial setting: Off
Tracks
Selects tracks and chapters for your FTS list.
Play list
Shows the programmed FTS list.
Note:
– For details about FTS and the settings of [Program] menu
items, see the descriptions followed by “FTS video/audio
program” on page 24.
View
Rotate
Rotates a JPEG image.
Choices: –180˚, –90˚, 0, +90˚, +180˚
Initial setting: 0
Zoom
Activates the zoom function. A cursor will be displayed on
screen. Move the cursor using the
v
w
t
u
buttons, then
select a size by pressing the ENTER button repeatedly. To
exit zoom mode, press RETURN/RESUME repeatedly
until the cursor disappears from the screen.
Chapter Preview
Plays the first 10 seconds of each chapter/track on the
disc. Pressing SCAN on the remote control performs the
same function as well.
Choices: On, Off
Initial setting: Off
Toolbar
