TL-WDR3500 N600 Wireless Dual Band Router
- 2 -
Chapter 1. Introduction
Thank you for choosing the TL-WDR3500 N600 Wireless Dual Band Router.
1.1 Overview of the Router
The TL-WDR3500 N600 Wireless Dual Band Router integrates 4-port Switch, Firewall, NAT-Router
and Wireless AP. Powered by 3x3 MIMO technology, the N600 Wireless Dual Band Router delivers
exceptional range and speed, which can fully meet the need of Small Office/Home Office (SOHO)
networks and the users demanding higher networking performance. Your wireless connections are
radio band selectable to avoid interference in your area.
Incredible Speed
T
he TL-WDR3500 N600 Wireless Dual Band Router provides up to 300Mbps (2.4GHz) + 300Mbps
(5GHz) wireless connection with other 802.11n wireless clients. The incredible speed makes it ideal
for handling multiple data streams at the same time, which ensures your network stable and smooth.
The performance of this 802.11n wireless Router will give you the unexpected networking experience
at speed much faster than 802.11g. It is also compatible with all IEEE 802.11g and IEEE 802.11b
products.
Multiple Security Protections
With multiple protection
measures, including SSID broadcast control and wireless LAN
64/128/152-bit WEP encryption, Wi-Fi Protected Access (WPA2- PSK, WPA- PSK), as well as
advanced Firewall protections, the TL-WDR3500 N600 Wireless Dual Band Router provides
complete data privacy.
Flexible Access Control
T
he TL-WDR3500 N600 Wireless Dual Band Router provides flexible access control, so that
parents or network administrators can establish restricted access policies for children or staff. It also
supports Virtual Server and DMZ host for Port Triggering, and then the network administrators can
manage and monitor the network in real time with the remote management function.
Simple Installation
Since the Router is comp
atible with virtually all the major operating systems, it is very easy to
manage. Quick Setup Wizard is supported and detailed instructions are provided step by step in
this user guide. Before installing the Router, please look through this guide to know all the
Router’s functions.
