Tp-Link TL-WDN3200 [10/45] Hardware overview

TL-WDN3200 N600 Wireless Dual Band USB Adapter

1.3 Hardware Overview

LED status:

Status Working Status

On The adapter has connected to a network. .

Flashing Slowly

The driver has been installed but no data is being transmitted or

received.

Flashing Quickly Data is being transmitted or received.

)Note:

When the adapter failed to connect to a wireless network, the LED may be off. Please choose

your network and try to connect again.
