TL-WR543G 54M Wireless AP Client Router User Guide
- 2 -
¾ Supports Port-based QoS.
¾ Output transmit power adjustable.
¾ Supports enabling/disabling the function of eXtended Range™ manually.
¾ Provides WPA/WPA2 and 64/128/152-bit WEP encryption security.
¾ Supports PPPoE, Dynamic IP, Static IP, L2TP, PPTP and Big Pond Cable Internet Access.
(AP Router mode only)
¾ Built-in NAT and DHCP server supporting static IP address distributing.
¾ Supports UPnP, Dynamic DNS, Static Routing, VPN Pass-through.
¾ Support Port QoS.
¾ Supports Parental Control, Virtual Server, Special Application and DMZ host.
¾ Built-in firewall supporting IP address filtering, Domain Name filtering, and MAC address
filtering.
¾ Provides WLAN ACL (Access Control List) (AP Router mode only).
¾ Supports configuration backup/restore and firmware upgrade.
¾ Supports Web management.
¾ Detachable Antenna (reverse SMA connector).
1.3 Panel Layout
1.3.1 The Front Panel
The front panel of the TL-WR543G consists of several LED indicators, which is designed to
indicate connections. View from left to right. Table 2-1 describes the LEDs on the front panel of
the router.
Figure 1-1 Front Panel sketch
LED Explanation：
