TL-WR543G 54M Wireless AP Client Router User Guide
- 3 -
Name Status Indication
Off Power off
PWR
On Power on
On The router is initializing or maybe has a system error.
Flashing The router is working properly
SYS
Off The router has a hardware error
Off There is no wireless device linked to the router
WLAN
Flashing The Wireless function is enabled
Off There is no device linked to the corresponding port
On
There is a device linked to the corresponding port but no
activity
WAN,1-4
Flashing There is an active device linked to the corresponding port
1.3.2 The Rear Panel
The following parts are located on the rear panel (View from left to right).
¾ AC power socket: Please use the power adapter which is supplied with the TL-WR543G
54M Wireless AP Client Router only, the use of a different adapter may
result in product damage.
¾ LAN 1,2,3,4: Four 10/100Mbps RJ45 LAN ports for connecting the router to the local
PC(s)
¾ WAN: This WAN port is where you will connect the cable/DSL Modem, or
Ethernet
¾ Reset button:
There are two ways to reset the router's factory defaults:
1) Use the Factory Defaults function on System Tools -> Factory Defaults page in the
router's Web-based Utility.
2) Use the Factory Default Reset button: First, turn off the router's power. Second, press
and hold the default reset button then turn on the router's power, until the SYS LED lights
up (about 3 seconds). Last, release the reset button and wait for the router to reboot.
)
Note:
Ensure the router is powered on before it restarts completely.
¾ Wireless antenna
