Section 6. Dening IP Addresses

This section provides information for dening IP addresses on the device using DHCP and ARP. In addition, this section

contains parameters for dening device default gateways, and Domain Name Servers.

This section contains the following topics:

Dening IP Addressing

Dening Domain Name System

6.1 Dening IP Addressing

Dening ARP

6.1.1 Dening IP Addresses

The IP Interface Page contains elds for assigning IP addresses. Packets are forwarded to the default IP when frames are

sent to a remote network. The congured IP address must belong to the same IP address subnet of one of the IP interfaces.

1. Click System > System Info > IP Conguration > IP Addressing. The IP Interface Page opens:

Figure 53: IP Interface Page

The IP Interface Page contains the following elds:

IP Address — Displays the currently configured IP

address.

Mask — Displays the currently congured IP address

Remove — Removes the selected IP address from the interface. The possible eld values are:

– Checked — Removes the IP address from the interface.

– Unchecked — Maintains the IP address assigned to the Interface.

2. Click . The Add IP Interface Page opens:












