Gigabit Broadband VPN Router User GuideTL-R600VPN

¾ Remote Management IP Address - This is the current address you will use when

accessing your router from the Internet. The default IP address is 0.0.0.0. It means this

function is disabled. To enable this function, change the default IP address to another IP

address as desired.

)

Note:

1) To access the router, you will type your router's WAN IP address into your browser's

address (in IE) or Location (in Navigator) box, followed by a colon and the custom port

number. For example, if your Router's WAN address is 202.96.12.8, and the port number

you use is 8080, please enter http://202.96.12.8:8080 in your browser. Later, you may be

asked for the router's password. After successfully entering the username and password,

you will be able to access the router's web-based utility.

2) Be sure to change the router's default password to a very secure password.

4.14.10 Statistics

Choose menu “System Tools→Statistics”, you can view the statistics of the Router. This screen

(shown in Figure 4-75 ) displays the network traffic of each PC on LAN, including total traffic and

current traffic of the last “Packets Statistic interval” seconds.

Figure 4-75

¾ Current Statistics Status - Enable or Disable the statistics function. The default status is

disabled. Click the Enable button to use the function. Click the Disable button to disable the

function.

¾ Packets Statistics Interval - The default value is 10. Select a value between 5 and 60

seconds in the pull-down list. The Packets Statistic interval value indicates the time section of

the packets statistic.

¾ Sort Rules - Select the rule for displaying the traffic information.

¾ Statistics Table - This table displays the statistics information about the traffic.
