Command Line Interface
4-242
4
show cluster candidates
This command shows the discovered Candidate switches in the network.
Command Mode
Privileged Exec
Example
Console#show cluster candidates
Cluster Candidates:
Role Mac Description
--------------- ----------------------------------------------------------
ACTIVE MEMBER 00-12-cf-23-49-c0 TL-SG5426
CANDIDATE 00-12-cf-0b-47-a0 TL-SG5426
Console#
