Glossary
Glossary-6
Virtual LAN (VLAN)
A Virtual LAN is a collection of network nodes that share the same collision domain
regardless of their physical location or connection point in the network. A VLAN
serves as a logical workgroup with no physical barriers, and allows users to share
information and resources as though located on the same LAN.
XModem
A protocol used to transfer files between devices. Data is grouped in 128-byte
blocks and error-corrected.
