TL-WR340G/TL-WR340GD 54M Wireless Router User Guide

by following these steps:

1. Click the Enable button to enable this function.

2. Select the radio button: Deny the stations not specified by any enabled entries in the list

to access for Filtering Rules.

3. Delete all or disable all entries if there are any entries already.

4. Click the Add New... button and enter the MAC address 00-0A-EB-00-07-BE in the MAC

Address field, enter wireless station A in the Description field, select Allow in the Privilege

pull-down list and select Enabled in the Status pull-down list. Click the Save and the Return

button.

5. Click the Add New... button and enter the MAC address 00-0A-EB-00-07-5F in the MAC

Address field, enter wireless station B in the Description field, select Deny in the Privilege

pull-down list and select Enabled in the Status pull-down list. Click the Save and the Return

button.

6. Click the Add New... button and enter the MAC address 00-0A-EB-00-07-8A in the MAC

Address field, enter wireless station C in the Description field, select 128-bit in the Privilege

pull-down list, enter 2F34D20BE2E54B326C5476586A in the WEP Key field and select

Enabled in the Status pull-down list. Click the Save and the Return button.

The filtering rules that configured should be similar to the following list:

)

Note:

If you select the radio button Allow the stations not specified by any enabled entries in the list to

access for Filtering Rules, the wireless station B will still not be able to access the router, however,

other wireless stations that are not in the list will be able to access the router.

If you enable the function and select the Deny the stations not specified by any enabled entries in

the list to access for Filtering Rules, and there are not any enable entries in the list, thus, no

wireless stations can access the router.

3.5.3 Wireless Statistics

This page shows MAC Address, Current Status, Received Packets and Sent Packets for each

connected wireless station.

Figure 3-21 The router attached wireless stations

¾ MAC Address - The connected wireless station's MAC address
