24-port NWay Ethernet Switch User’s Guide
Identifying External Components 17
1000BASE-SX Gigabit Module
Figure 3-6. 1000BASE-SX gigabit one-port module
Rear-panel module.
Connects to 1000BASE-SX devices at full duplex only.
Extends network diameter from 260 meters to 550 meters
depending on the type of fiber optic cable used.
LED Indicators
The LED indicators of the Switch include Power, Console, Slot,
Giga, Speed, and Link/Act. The following shows the LED indicators
for the Switch along with an explanation of each indicator.
Figure 3-10. The LED indicators
Power This indicator on the front panel should be colored
amber during the Power-On Self Test (POST). It will light
green approximately 2 seconds after the switch is powered on
to indicate the ready state of the device. The LED will blink
green while downloading new software for the switch, or if
