Manual Supplement 114, 115, 116, and 117 Calibration Information
Hz (V or A input)
[2]
99.99 Hz
999.9 Hz
9.999 kHz
50.00 kHz
99.99 kHz
0.01 Hz
0.1 Hz
0.001 kHz
0.01 kHz
0.01 kHz
0.1 % + 2 115, 117
Notes:
[1] All ac ranges except Auto-V LoZ are specified from 1 % to 100 % of range. Auto-V LoZ is specified from 0.0 V.
Because inputs below 1 % of range are not specified, it is normal for this and other true-rms meters to display non-
zero
readings when the test leads are disconnected from a circuit or are shorted together. For volts, crest factor of ≤3 at
4000 counts, decreasing linearly to 1.5 at full scale. For amps, crest factor of ≤3. AC volts is ac-coupled. Auto-V LoZ,
AC mV, and AC amps are dc-coupled.
[2] AC Volts Hz is ac-coupled and specified from 5 Hz to 99.99 kHz. Minimum input required above 50.00 kHz typically is
> 1.1 vac sine. Minimum input typical and not specified. AC Amps Hz is dc-coupled and specified from 45 Hz to 5 kHz.
[3] W>10 A accuracy is unspecified. Duty cycle: >10 A to 20 A, 30 seconds on, 10 minutes off.
Change #3
On page 2, under Safety Information:
Change:
Do not use the Meter around explosive gas or vapor.
To:
Do not use the Product around explosive gas, vapor, or in damp or wet environments
Change #4, 63151, 63405, 543, 238
On page 3, replace Table 1 with:
Table 1. Electrical Symbols
Symbol Description Symbol Description
B� AC (Alternating Current) I� Fuse
F� DC (Direct Current) T� Double Insulated
X�
WARNING - RISK OF DANGER. Consult
user documentation.
W�
WARNING. RISK OF DANGER
Battery (Low battery when shown on the
display.)
J�
Earth ground
~�
This product complies with the WEEE Directive marking requirements. The affixed label indicates that you
must not discard this
electrical/electronic product in domestic household waste. Product Category: With
reference to the equipment types in the WEEE Directive Annex I, this product is classed as category 9
"Monitoring and Control Instrumentation" product. Do not dispose of this
product as unsorted municipal
waste.
� Conforms to relevant South Korean EMC Standards
CAT II
Measurement Category II is applicable to test and measuring circuits connected directly to utilization points
(socket outlets and similar points) of the low-voltage MAINS installation.
CAT III
Measurement Category III is applicable to test and measuring circuits connected to the distribution part of
the building’s low-voltage MAINS installation.
CAT IV
Measurement Category IV is applicable to test and measuring circuits connected at the source of the
building’s low-voltage MAINS installation.
)
Certified by CSA Group to North American safety standards.
®
Certified by TÜV SÜD Product Service.
»�
�
Consult user documentation.
2 7/18
