![Ciat Splitciat SEO 24 L Инструкция по эксплуатации онлайн [14/18] 366072](/views2/1437006/page14/bge.png)
14
P15 Ambiance consigne
La télécommande affiche en permanence la température
ambiante (P15 = 0) au niveau de la télécommande. Il est
néanmoins possible de ne visualiser que la température de
consigne en donnant au paramètre P15 la valeur 1.
P16 Limite hors gel
La fonction hors gel accessible en mode chaud par la touche
(S) maintient une température de 10 °C (réglage usine) dans
le local. Cette valeur est modifiable par le paramètre P16 dans
une plage de 10 à 19 °C.
P17 Ajustement sonde CPU
P18 Ajustement sonde télécommande
Il est possible d’ajuster la valeur (P17) des sondes de reprise
assurant la régulation ou la valeur (P18) de la télécommande
assurant l’affichage sur le LCD.
Ces valeurs sont ajustables de + 6 à – 6 °C.
P17/P18 permettent de corriger les valeurs des sondes afin
d’éviter les désagréments lié au gradiant de températures ou
à l’emplacement de la télécommande à fil.
P19 Compteur filtre (200 à 2000)
L’appareil informe l’utilisateur de la nécessité de contrôler
l’état du filtre à air à intervalle de temps régulier.
Ce laps de temps fixé en usine à 800 heures peut être modifié
selon le lieu d’implantation des appareils de 200 à 2000
heures par pas de 100 h.
P23 Sonde TC / reprise
Dans le cas de télécommande à fil (régulation sur l’ambiance)
il est nécessaire de donner au paramètre P 23 la valeur 0. Il
est possible en ajoutant une sonde à la reprise de l’appareil
d’effectuer une régulation sur l’air repris. Dans ce cas, il est
nécessaire de donner au paramètre P23 la valeur 1.
1 = sonde de reprise
0 = sonde de la télécommande (régulation sur l’ambiance).
P24 Auto Test
P24 = 1 AUTO TEST EN FROID - Durée 2 mn
Vérification de bon fonctionnement en Froid et des
sondes de régulation
P99 Type d’appareil
Paramètre spécifique à chaque type d’unité, réglé en usine.
Pour les appareils de type SEO, cette valeur doit
impérativement rester à P99 = 0.
Pour les appareils de type SYEO cette valeur doit
impérativement restée à P99 = 1.
P15 Setting ambiance
The remote control displays in permanence the ambient
temperature (P15=0) at the remote control level. It is however
possible to visualize only the setting temperature by giving the
value 1 to parameter P15.
P16 Anti-frost limit
The anti-frost function, accessible in the heating mode
through key (S) maintains a 10
°
C temperature (factory
setting) in the room. This value can be modified by parameter
P16 within a range from 10 to 19
°
C
P17 CPU sensor adjustment
P18 Remote control sensor adjustment
It is possible to adjust the value (P17) of the intake sensors
ensuring the regulation, or the value (P18 of the remote
control ) ensuring the display on the LCD.
These values are adjustable from + 6 to – 6
°
C.
Parameters P17/P18 permit to correct the sensor values so
as to avoid the inconvenience of the temperature gradient or
the position of the wire remote control.
P19 Filter counter (200 to 2000)
The unit informs the user of the necessity to check the air filter
at regular intervals.
This time interval, fixed in factory at 800 hours, can be
modified, according to the location of units, from 200 to 2000
hours by intervals of 100 hours.
P23 Remote control / intake sensor
In the case of a wire remote control (regulation on the room
temperature), value 0 must be given to parameter P 23. It is
possible, by adding a sensor at the unit intake, to make a
regulation on the air intake. In this case, value 1 must be given
to parameter P23.
1 = Intake sensor
0 = Remote control sensor (room temp. control).
P24 Autotest
P24 = 1 AUTO TEST IN COOLING – 2 mn duration
Verification of cooling mode and control sensors
correct operation.
P99 Type of unit
Parameter specific to each type of unit, set in factory.
For SEO type units, this value must remain at P99 = 0
For SYEO type units, this value must remain at P99 = 1.
