D-Link DES-3326S Layer 3 Switch
The following fields can be set for IGMP Interfaces:
Parameter Description
Interface Name <System>
Displays the name of the IP interface that is to be configured for IGMP. This must
be a previously configured IP interface.
IP Address
Displays the IP address corresponding to the IP interface name above.
Version <2>
Enter the IGMP version (1 or 2) that will be used to interpret IGMP queries on the
interface.
Query Interval <125>
Allows the entry of a value between 1 and 65535 seconds, with a default of 125
seconds. This specifies the length of time between sending IGMP queries.
Max Response Time <10>
Sets the maximum amount of time allowed before sending an IGMP response
report. A value between 1 and 25 seconds can be entered, with a default of 10
seconds.
Robustness Variable <2>
A tuning variable to allow for subnetworks that are expected to lose a large
number of packets. A value between 2 and 255 can be entered, with larger values
being specified for subnetworks that are expected to lose larger numbers of
packets.
149
