D-Link DES-3326S Layer 3 Switch
The following RIP settings can be applied to each IP interface:
Parameter Description
Interface Name
The name of the IP interface on which RIP is to be setup. This interface must be
previously configured on the Switch.
TX Mode <Disabled>
Toggle among Disabled, V1 Only, V1 Compatible, and V2 Only. This entry specifies
which version of the RIP protocol will be used to transmit RIP packets. Disabled
prevents the transmission of RIP packets.
RX Mode <Disabled>
Toggle among Disabled, V1 Only, V2 Only, and V1 or V2. This entry specifies which
version of the RIP protocol will be used to interpret received RIP packets. Disabled
prevents the reception of RIP packets.
Password
A password to be used to authenticate communication between routers on the network.
Authentication
Toggle between Disabled and Enabled to specify that routers on the network should us
the Password above to authenticate router table exchanges.
State
Toggle between Disable and Enable to disable or enable this RIP interface on the
Switch.
156
