D-Link DES-3326S Layer 3 Switch

Parameter Description

Profile ID

Type in a unique identifier number for this profile set or allow an ID to be automatically

assigned by checking the Auto Assign option. This value can be set from 1 – 255. The

profile ID sets the relative priority for the profile and specifies an index number that will

identify the access profile being created with this command. Priority is set relative to other

profiles where the lowest profile ID has the highest priority.

Access Profile

Select profile based on Ethernet (MAC Address) or IP address. This will change the menu

according to the requirements for the type of profile. Select Ethernet to instruct the switch to

examine the layer 2 part of each packet header. Select IP to instruct the switch to examine

the IP address in each frame’s header.

VLAN

Selecting this option instructs the switch to examine the VLAN part of each packet header

and use this as the, or part of the criterion for forwarding.

Source IP Mask

Enter an IP address mask for the source IP address.

Destination IP Mask

Destination IP Mask - Enter an IP address mask for the destination MAC address.

DSCP

Selecting this option instructs the switch to examine the DiffServ Code part of each packet

header and use this as the, or part of the criterion for forwarding.

Protocol*

(for IP address

Access Profiles only)

*TCP flag mask

parameter can be

implemented using

the CLI interface.

This option is not

available using the

web interface.

Selecting this option instructs the switch to examine the protocol type value in each frame’s

header. You must then specify what protocol(s) to include according to the following

guidelines:

Select ICMP to instruct the switch to examine the Internet Control Message Protocol

(ICMP) field in each frame’s header.

Select Type to further specify that the access profile will apply an ICMP type value, or

specify Code to further specify that the access profile will apply an ICMP cod value.

Select IGMP to instruct the switch to examine the Internet Group Management Protocol

(ICMP) field in each frame’s header.

Select Type to further specify that the access profile will apply an IGMP type value

Select TCP to use the TCP port number contained in an incoming packet as the forwarding

criterion. Selecting TCP requires that you specify a source port mask and/or a destination

port mask.

Source Port Mask Ox - Specify a TCP port mask for the source port in hex form (hex 0x0-

0xffff).

Destination Port Mask Ox - Specify a TCP port mask for the destination port in hex form

(hex 0x0-0xffff).

Select UDP to use the UDP port number contained in an incoming packet as the forwarding

criterion. Selecting UDP requires that you specify a source port mask and/or a destination
