Appendix B - IP Address ConfigurationAppendix B - IP Address Configuration
Appendix B - IP Address ConfigurationAppendix B - IP Address Configuration
Appendix B - IP Address Configuration
To connect to a network, make sure the proper
network settings are configured for DWL-G650M.
Microsoft Windows XP:
Go to Start, right click on My Network Places,
select Properties, and Double-click on the
Network Connection associated with the
DWL-G650M.
Input a static IP address in the same range
as the Wireless Router or Access Point.
Static IP address setup
Click OK
IP address: 192.168.0.52
Subnet mask: 255.255.255.0
Click OK
Click Internet Protocol (TCP/IP)
Click Properties
Select Obtain an IP address
automatically (if the Wireless Router or
Access Point has DHCP server enabled)
Select Obtain DNS server
address automatically
Dynamic IP address setup
Used when a DHCP server is available on
the local network. (i.e. Router)
Used when a DHCP server is not available
on the local network.
Select Use the following IP address
D-Link Super G MIMO DWL-G650M
