11
Windows 2000 users:
Go to Start > Settings > Network and
Dial-up Connections > Double-click on the
Local Area Connection associated with
the DWL-G650M > select Properties
Used when a DHCP server is available on
the local network. (i.e. Router)
Static IP address setup
Input a static IP address in the same range as
the Wireless Router or Access Point.
Click Properties
Click OK
Click OK
Click Internet Protocol (TCP/IP)
Select Obtain an IP address
automatically (if the Wireless Router or
Access Point has DHCP server enabled)
Select Obtain DNS server
address automatically
Select Use the following IP address
Dynamic IP address setup
Used when a DHCP server is not available
on the local network.
IP address: 192.168.0.52
Subnet mask: 255.255.255.0
Appendix B - IP Address ConfigurationAppendix B - IP Address Configuration
Appendix B - IP Address ConfigurationAppendix B - IP Address Configuration
Appendix B - IP Address Configuration
D-Link Super G MIMO DWL-G650M
