6
YY
YY
Y
our Installation is Complete!our Installation is Complete!
our Installation is Complete!our Installation is Complete!
our Installation is Complete!
After the installation, the Configuration Utility will automatically start and the utility icon
will appear in the bottom right hand corner of the desktop screen (systray). If this icon
appears GREEN, then you have successfully installed the DWL-G650M, are
connected to a wireless network and are ready to communicate!
Double-click the utility icon to
use the configuration utility.
If the utility icon does not appear,
double-click the shortcut icon that
has appeared on your desktop.
AppendixAppendix
AppendixAppendix
Appendix
WPA-PSK:
WPA-Personal is directed at home users who do not have the server based equipment
required for user authentication. The method of authentication is similar to WEP because
you define a “Pre-Shared Key” on the wireless router/AP. Once the pre-shared key is
confirmed and satisfied on both the client and access point, then access is granted. the
encryption method used is referred to as the Temporal Key Integrity Protocol (TKIP), which
offers per-packet dynamic hashing. It also includes an integrity checking feature which
ensures that the packets were not tampered with during wireless transmission.
