11
Getting Started
Setup #2
DWL-810+
Setup #2: This example illustrates an Infrastructure setup. To
connect the DWL-810+ to a wireless network with a wireless router
or access point, please refer to the printed Quick Installation Guide
included with the product. Web configuration is required to connect
the DWL-810+ in Setup #2.
