6
Connections
Reset Button – press this button to revert to the factory default settings of
the DWL-810+
Power Receptor – connect one end of the 5V DC Power Adapter (included)
to the power receptor on the DWL-810+ and connect the other end of the
Power Adapter to a power outlet.
Default Settings
Operating Mode Infrastructure
SSID default
Channel 6
Transmission rates Auto
Encryption Disabled
IP Address 192.168.0.30
IP Subnet 255.255.255.0
User Name admin (all lower case)
Password None (leave field blank)
Ethernet Port
Reset Button
Power Receptor
Category 5 is the most reliable grade of twisted-pair cable. It is available as
either Straight-Through cable or Cross-Over cable. Always check your
installation instructions to make sure that you have selected the correct type of
Category 5 cable for your other
networking devices. The DWL-810+ will accept
either kind of cable and will automatically sense the cable that you are using.
Ethernet Port
–
this RJ-45
A
uto
MDI/MDIX port provides
connection to a network device
using a Cat 5 Ethernet cable.
(The auto MDI/MDIX port
accommodates either Straight-
Through or Cross-Over cable and
is auto-sensing.)
